  6-1/8" 2 WAY SWITCH DPDT, MOTOR DRIVE
방송 송신용 RF Coaxial Switch

1. 커넥터: 6 1/8" EIA
2. port 수: 4개
3. MOTOR DRIVE
4. Operating voltage: 230 VAC ± 10%, 50~60 Hz
5. Impedence: 50 ohm
  4-1/2",399 IEC 50-105 2 WAY SWITCH DPDT, MOTOR DRIVE
방송 송신용 RF Coaxial Switch

1. 커넥터: 4 1/2" EIA, 399 IEC 50 - 105
2. port 수: 4개
3. MOTOR DRIVE
4. Operating voltage: 230 V AC ± 10%, 50~60 Hz
5. Control voltage: 24 V DC ± 10%
6. Impedence: 50 ohm
  3-1/8" 2 WAY SWITCH DPDT, MOTOR DRIVE
방송 송신용 RF Coaxial Switch

1. 커넥터: 3 1/8" EIA
2. port 수: 4개
3. MOTOR DRIVE
4. Operating voltage: 230 V AC ± 10%, 50~60 Hz
5. Control voltage: 24 V DC ± 10%
6. Impedence: 50 ohm
  2 WAY SWITCH DPDT, SOLENOID DRIVE, LATCHING
방송 송신용 RF Coaxial Switch

1. 커넥터: N type Coupler
2. port 수: 4개
3. SOLENOID DRIVE
4. Impedence: 50 ohm
  2 WAY SWITCH DPDT, SOLENOID DRIVE, LATCHING
방송 송신용 RF Coaxial Switch
1. 커넥터: N type Coupler
2. port 수: 4개
3. SOLENOID DRIVE
4. Impedence: 50 ohm
  2 WAY SWITCH DPDT, SOLENOID DRIVE, LATCHING
방송 송신용 RF Coaxial Switch
1. 커넥터: N type Coupler
2. port 수: 4개
3. SOLENOID DRIVE
4. Impedence: 50 ohm
  1-5/8" 2 WAY SWITCH DPDT, MOTOR DRIVE
방송 송신용 RF Coaxial Switch

1. 커넥터: 1 5/8" EIA
2. port 수: 4개
3. MOTOR DRIVE
4. Operating voltage: 230 V AC ± 10%, 50~60 Hz
5. Control voltage: 24 V DC ± 10%
6. Impedence: 50 ohm
  7/8" 2 WAY SWITCH DPDT, MOTOR DRIVE
방송 송신용 RF Coaxial Switch

1. 커넥터: 7/8" EIA
2. port 수: 4개
3. MOTOR DRIVE
4. Operating voltage: 230 V AC ± 10%, 50~60 Hz
5. Control voltage: 24 V DC ± 10%
6. Impedence: 50 ohm
  2 WAY SWITCH DPDT, SOLENOID DRIVE, LATCHING
방송 송신용 RF Coaxial Switch

1. 커넥터: 7-16 type Coupler
2. port 수: 4개
3. SOLENOID DRIVE
4. Impedence: 50 ohm
  6-1/8" Coaxial Switch 방송용 RF Coaxial Switch

1. 커넥터 사이즈: 6-1/8"
2. Port 수: 3,4개
3. Drive motor (50/60Hz) 전원사양
230VAC (1.3amps/0.7 ampr)
115VAC (1.7amps/0.8 ampr)
4. 외부 원격조정 스위치 전원사양: 125VAC (8amps)
5. Impedence: 50 & 75 ohm
  4-1/16" Coaxial Switch
방송 송신용 RF Coaxial Switch

1. 커넥터 사이즈: 4-1/16"
2. Port 수: 3,4개
3. Drive motor (50/60Hz) 전원사양
230VAC (0.93 amps/0.50 ampr)
115VAC (1.3 amps/0.60 ampr)
4. 외부 원격조정 스위치 전원사양: 125VAC (8amps)
5. Impedence: 50 ohm
  3-1/8" Coaxial Switch
방송 송신용 RF Coaxial Switch

1. 커넥터 사이즈: 3-1/8"
2. Port 수: 3,4개
3. Drive motor (50/60Hz) 전원사양
230VAC (0.93 amps/0.50 ampr)
115VAC (1.3 amps/0.60 ampr)
4. 외부 원격조정 스위치 전원사양: 125VAC (8amps)
5. Impedence: 50 ohm
  1-5/8" Coaxial Switch
방송 송신용 RF Coaxial Switch

1. 커넥터 사이즈: 1-5/8"
2. Port 수: 3,4개
3. Drive motor (50/60Hz) 전원사양
230VAC (0.93amps/0.50ampr)
115VAC (1.3amps/0.60ampr)
4. 외부 원격조정 스위치 전원사양: 125VAC (8amps)
5. Impedence: 50 ohm
  9-3/16" coaxial switch
방송 송신용 RF Coaxial Switch


1. 커넥터 사이즈: 9-3/16"
2. Port 수: 3,4개
3. Drive motor (50/60Hz) 전원사양
230VAC (1.5amps/0.3ampr)
115VAC (3.5amps/0.5ampr)
4. 외부 원격조정 스위치 전원사양: 125VAC (8amps)
5. Impedence: 50 & 75 ohm
  7/8" Coaxial Switch

방송 송신용 RF Coaxial Switch

1. 커넥터 사이즈: 7/8"
2. Port 수: 4개
3. Drive motor (50/60Hz) 전원사양
230VAC (0.1amps)
115VAC (0.2amps)
24VDC (0.7amps)
4. 외부 원격조정 스위치 전원사양: 125VAC (8amps)
5. Impedence: 50 ohm
